Tube laser cutting
Tube laser cutting is a modern and efficient method that enables precise and versatile processing of various tubes and profiles. This technology allows the production of components and structures for a wide range of applications, such as construction, machinery manufacturing, furniture industry, automotive industry, and electrical engineering.
Trumpf TruLaser Tube 7000 tube laser
At our Piikkiö facility, we operate a state-of-the-art 3D Trumpf TruLaser Tube 7000, which offers advanced material processing capabilities. It works seamlessly alongside our sheet laser, punching center, and multiple bending and folding machines — ensuring a highly efficient production line.
Precision and efficiency in metalworking
Tube laser cutting enables the processing of complex cuts, holes, and openings in a single setup. It supports various materials, including aluminum, steel (FE), stainless steel (AISI 304, AISI 316), brass, and copper. The process optimizes raw material usage, minimizing waste and reducing costs.
In addition, tube laser cutting significantly boosts production efficiency by reducing the need for separate work phases such as drilling, milling, and sawing.
Technical specifications:
- Laser power: 4 kW
- Bevel cutting capability
- Cutting capacity:
RHS-profiles: max 180 x 180 mm - Round tubes: max Ø 254 mm
- Other geometries are also supported
- Freeform profiles: max Ø 254 mm
- Minimum profile diameter: 12 mm
- Cutting capacity:
- Loading length: max 10200 mm
- Maximum finished part length: max 8000 mm
- Maximum part weight: max 40 kg/m
- Processable Materials: Aluminium, steel (FE), stainless steel (AISI 304, AISI 316), brass, copper
